WashBoost™ Pro
The KGN Pillinger WashBoost™ Pro represents the highest specification within the WashBoost™ range, designed specifically for process-critical applications where uninterrupted water supply is essential. As a step up from the WashBoost™ Twin, this advanced system incorporates a Form 4 local control panel, allowing full system maintenance without interruption to site operations and ensuring maximum uptime and reliability.
Product Variations
- WashBoost™ Pro 1505 Booster System
- WashBoost™ Pro 2205 Booster System
- WashBoost™ Pro 3303 Booster System
- WashBoost™ Pro 4603 Booster System
Key Benefits
- Engineered for process-critical plant applications
- Form 4 control panel enables maintenance without system shutdown
- High level of system resilience and operational continuity
- Optional pre-constructed enclosure for fast installation
- Separation of ‘wet’ and ‘dry’ compartments for enhanced safety
- Designed for safe lifting and long-term asset management
Design & Construction
The WashBoost™ Pro is engineered for high performance, safety and operational efficiency in demanding environments:
- Fully packaged booster system based on the Twin configuration
- Optional pre-constructed enclosure, delivered complete to site
- Enclosure designed with dedicated ‘wet’ and ‘dry’ compartments
- Robust construction for long-term durability
The modular enclosure solution allows quick installation while protecting sensitive components and simplifying maintenance.
Control & Monitoring
- Form 4 local control panel for advanced electrical segregation
- Allows maintenance without interrupting live operation
- Local delivery pressure readings available in both the ‘wet’ and ‘dry’ compartments
This provides clear system visibility and ensures operational control at all times.
Key Features
- High-specification booster system for critical applications
- Form 4 control panel for uninterrupted maintenance
- Optional pre-constructed enclosure
- Separate ‘wet’ and ‘dry’ internal zones
- Designed for safe lifting and maintenance access
- Dual-location pressure monitoring
- Built for reliability, safety and long-term operation
Typical Applications
- Process-critical water systems
- Water utility treatment works
- Industrial facilities requiring continuous washdown supply
- Sites with strict uptime and operational resilience requirements
Installation
Flexible and efficient installation options include:
- Supplied as a fully packaged booster unit
- Optional enclosure delivered pre-constructed and installed on-site
- Designed for straightforward integration
Performance & Reliability
The WashBoost™ Pro is designed to deliver maximum uptime and operational assurance in demanding environments.
Its advanced control panel configuration ensures that maintenance can be carried out without interrupting system performance, making it ideal for critical infrastructure applications.
